Blue Sea 8462 AC 2 Sources + 9 Positions

AC 2 Sources + 9 Positions

(2) 30A Double Pole Circuit Breakers

(6) 15A Single Pole Circuit Breakers

• Double pole AC main circuit breakers with installed lockout slide

• Prevents connecting both AC sources simultaneously

• Maximum panel amperage - 50 Amperes

• Red reverse polarity indicating LED

• All hot, neutral and safety ground buses installed, fully pre-wired

• All circuit label positions are backlit on standard panels - No kit required

• "ON" indicating LEDs installed in all circuit positions

• MIL-C-5541C or equivalent immersion undercoating for lifetime corrosion resistance

• Two-part polyurethane slate gray finish

• Heavy 1/8" aluminum 5052 alloy

• Industry standard height and width

• Countersunk mounting holes throughout

• Detailed installation instructions and cutout template included

  WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

  Specifications:

  • Voltage: 120v
  • AC/DC: AC
  • Max Breaker Quantity: 9
  • Box Dimensions: 5"H x 9"W x 11"L WT: 4.15 lbs
  • UPC: 632085084622
